Automatic Blow Molding Machine

images

Low Price Good Quality Water Bottle Small Plastic Bottle Making Machine

Servo transmission system
High positioning accuracy, fast speed and stability, good reliability. Gas circuit design will divide action and blowing into three parts to meet the needs of different pressure for blowing bottles and movement; Adopt high pressure and double crank arm link locking, strong clamping force.
Adopt infrared lamp heating
Adopt infrared lamp heating, strong penetration, preform rotation heating, track revolution, heating evenly, fast and reliable; Heating lamp, reflector width and height can be adjusted to suit preform heating of different structure, with automatic temperature-removal device to ensure the constant temperature of oven.

Model BG-4000D
Theoretical output 1600-1800 pcs/h


Finished bottle		 Max. bottle volume 1.5 Liters
Max. neck diameter 38 mm
Max. bottle diameter 110 mm
Max. bottle height 250 mm

Mold specifications		 Cavity 2 cavity
Mold thickness 110mm-160mm
Open stroke 130 mm

Electrical system		 Power voltage 380v/3Phase/50HZ
Installation power 35 kw
Actual power consumption 18 kw
Air source Recommend air compressor <1.6m³/min 30Kg
Cooling water Recommend water chiller 3HP
Blower size Length*width* height/weight 1600*115* 1880(MM) / 1000 kg
Feeder size Length*width* height/weight 1800*1400*2400mm(MM) / 200 kg
